Description

LOA 50,09 m
Beam 13 m
Draft 4 m

Built in year 2015
Class : American Bureau of Shipping
Flag : Marshall Islands
Gross Tonnage of 1.255 and Nett Tonnage of 376

Dynamic Positioning of class : DP 2
Free Deck area about 166m² with a deck strength of 7,5 metric tonnes per square meter
4-Point installed
Fire Fighting System installed
1 KNB installed with a max lifting capacity of 25 tons
Deadweight : 689 metric tonnes
Capable of supplies of 265m³ Fuel Oils and 196m³ FW

Total 56 berths
4 cabins with 2 berths
2 cabins with 1 berth
8 cabins with 1 berth
4 cabins with 2 berths
4 cabins with 4 berths
6 cabins with 1 berth
2 cabins with 4 berths

Speed : 12 knots
Engines : 2 x Caterpillar / Caterpillar Inc 3512B, 2.850 kw, 1.600 rpm, Propellers 1 Fixed Pitch (Port Side) + 1 Fixed Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 320 kw + 1 Caterpillar 492 kw, Bowthruster + Sternthruster (1 Bow Thwart. CP thruster 300kw + 1 Stern Water jet 330kw)

Specifications

Engine(s)

2 x 2.850 kw, 1.600 rpm, Caterpillar / Caterpillar Inc 3512B,
Propellers: 1 Fixed Pitch (Port Side) + 1 Fixed Pitch (Starboard)
